The IronCAD Design Collaboration Suite, including IRONCAD, INOVATE, IRONCAD DRAFT, and IRONCAD COMPOSE, is a Windows-based design software. Version 2018 and newer supports only 64-bit versions of the Windows operating system. Previous versions support both 32 and 64-bit on supported operating system platforms.
Below is a table that cross-references releases of IronCAD products with compatible Windows platforms.
In addition, your PC will need the following to run IronCAD:
- 64-Bit Window Operating System
- A Pentium 4 CPU or higher (current AMD processors supported)
- 4GB Recommended (8 GB or more for large assembly work)
- Direct X and/or OpenGL compatible accelerated video graphics card (required for large assembly work)
- 2 GB of free disk space to install. More recommended for design data.
- Windows 10/11 – Recommended having all the latest Windows updates.
- See example of a certified machine configuration.
IRONCAD/INOVATE/COMPOSE/DRAFT
| Windows Version | ||||||||
|---|---|---|---|---|---|---|---|---|
| Product Version | Windows 11 | Windows 10 | Windows 8.1 | Windows 8 | Windows 7 | Windows Vista | Windows XP | |
| 2024 | ||||||||
| 2023 PU1 | ||||||||
| 2023 | ||||||||
| 2022 PU1 | * | |||||||
| 2022 | ||||||||
| 2021 | ||||||||
| 2020 | ||||||||
| 2019 | ||||||||
| 2018 | ||||||||
| 2017 | ||||||||
| 2016 | ||||||||
| 2015 PU1 | ||||||||
| 2015 | ||||||||
| 2014 | ||||||||
| 2013 | ||||||||
| 2012 | ||||||||
| 2011 | ||||||||
| 2009 | ||||||||
| V11 PU1 | ||||||||
| V11 | ||||||||
Note:
- Home editions of Windows are not supported.
- * – Windows 7 Support for Native Translator Stopped on Release of 2022.
Network License Manager
| Windows Version | |||||||
|---|---|---|---|---|---|---|---|
| Product Version | Windows 11 | Windows 10 | Windows 8.1 | Windows 8 | Windows 7 | Windows Vista | Windows XP |
| SENTINEL | |||||||
| CAXA | |||||||
| Windows Server Version | ||||||||
|---|---|---|---|---|---|---|---|---|
| Product Version | 2022 | 2019 | 2016 | 2012 R2 | 2012 | 2008 R2 | 2008 | 2003 |
| SENTINEL | ||||||||
| CAXA | ||||||||
Note: Only Microsoft Windows networks are supported.
Example certified machine configuration:
- HP Z240 Workstation
- CPU: E3-1240 V5 @3.50 GHZ
- OS: Windows 10 64-bit
- RAM: 16 GB
- Graphics Card: Nvidia Quadro K620 with 2 GB Memory
- Hard Disk: NVMe Samsung M2VPV128 SSD 128 GB
